P3-32S INDOOR LED DISPLAY MAIN SPECIFICATION

PIXEL PITCH 3㎜

PANELS SIZE 192x192mm

CABINET SIZE 576x576(mm)

DENSITY 111111 dot/㎡

PIXEL CONSTITATION 1R1G1B

PANELS PIXEL 64*64=4096 DOTS

PANELS WEIGHT 0.24 kg

CABINET RESOLUTION 192x192mm

CABINET AREA 0.331776m²

CABINET WEIGHT 6.8KG±0.05KG

MAIN TECHNICAL PARAMETERS

OPTIMUM VIEWING DISTANCE 3m～38m

VISUAL ANGEL HORIZONTAL≧160°OPTION

VERTICAL≥160°OPTION

AVERAGE POWER CONSUMPTION         ＜600W/㎡

MAXIMUM POWER CONSUMPTION       ＜1300w/㎡

CONTROL MODE:SYNCHRONOUS

DISPLAY CARD: DVI CARD

SCAN MODE: 1/32S

MAXIMUM POWER≤12W

REPETITION FREQUENCY≧360Hz

WHITE BALANCE BRIGHTNESS         ≧1000cd/㎡

REFRESH RATE≥500Hz

BRIGHTNESS CONTROL MODE

AUTOMATIC BRIGHTNESS SENSING ADJUSTMENT

ADJUSTABLE LEVEL 16

SOFTWARE MANUAL ADJUSTMENT:100 LEVEL ADJUSTABLE 100

COMPUTER OPERATING SYSTEM

WIN98、WINXP、WIN2000,etc

THE VIDEO SIGNAL

RF、S-Video、RGB、RGBHV、YUV、YC、COMPOSITION ETC

CONTROL SYSTEM

PCTV CARD（optional）+DVI CARD+MASTER CARD+OPTICAL FIBER TRANSMISSION（optional）

MEAN FREE ERROR TIME ≧5000H

LIFETIME 75000～100000H

OUT OF CONTROL RATE  ＜0.0002 PCS

ITEM PH3-32S

3 IN 1

LEDS 2121
